Energy Saving, Exhaust-Recovery Booster Regulator

Series VBAE

Energy Saving, Exhaust-Recovery Booster Regulator

  • CO2 emissions (Air consumption) :Max. 40% reduction
    (Based on SMC's measuring conditions)
    Driven by reusing the exhaust air
  • Increase factory air pressure by 1.7 times Air-only operation that requires no power supply, and allows for easy installation
  • Operation noise: 65 dB (A)
    15 dB (A) reduction compared with the existing model (VBA series) (Based on SMC's measuring conditions)
  • Charging time: Max. 50% shorter
    Reduced maintenance frequency due to improved life
    (Based on SMC's measuring conditions)
  • Compatible with vertical and horizontal installation
  • Mounting interchangeability with the existing model (VBA series).

Standard Air Cylinder (Square Cover)

Series MB2

Standard Air Cylinder (Square Cover)

  • 3 times better durability due to the air cushion + rubber bumper structure
  • Allowable kinetic energy: Max. 1.5 times
    Has the same kinetic energy as the existing MB series product which is 1 size larger
  • CO2 emissions (Air consumption) can be reduced by up to 39%
    CO2 emissions (Air consumption) can be reduced due to downsizing (Air consumption for one cycle)
  • The overall length, mounting dimensions, and mounting brackets are interchangeable with the existing MB series product.

Electric Vacuum Gripper for Collaborative Robots

Series ZXPE5

Electric Vacuum Gripper for Collaborative Robots

  • Can be used with the collaborative robots of 4 companies
    UNIVERSAL ROBOTS
    OMRON/TECHMAN ROBOT [New]
    FANUC CORPORATION [New]
    ASKAWA Electric Corporation [New]
  • A vacuum gripper that doesn't require an air source
  • Operation possible by simply connecting an electrical wire connector
    Can be used without an air source due to the built-in vacuum pump
  • Unitization of the peripheral devices required for adsorption
    The vacuum pump, atmospheric release valve, pressure monitor, and cups have been integrated
  • Current consumption: Max. 64% reduction
  • Energy-saving operation possible via automatic/manual modes
  • Lightweight: 556 g
  • A wide variety of cup variations are available to support a wide range of workpiece shapes
  • Standards: Conforming to ISO9409-1-50-4-M6.

Longer Life Cylinder

Series C55-XB24

Longer Life Cylinder

  • New technology offers at least 4 times better durability
  • The maintenance intervals will be extended
  • Employs the same specifications and dimensions as the existing model, C55 ISO Cylinder series
  • ISO Standards (21287).

Compact 5-Port Solenoid Valve A top-ported type

Series JSY3000

Compact 5-Port Solenoid Valve A top-ported type

  • A top-ported type has been added to the JSY3000 series
  • 4(A) and 2(B) port output pressure detection is possible
    (Caution) The mounting bases are side ported.

Vacuum Gripper System (Foam Type)

Series ZGS

Vacuum Gripper System (Foam Type)

  • Suitable for the palletizing and depalletizing of corrugated cardboard, etc.
  • Combines all functions required for adsorption
    Ejector unit
    (Ejector, Supply valve/Release valve, Silencer, Pressure switch)
  • Can be used immediately by simply connecting 1 electrical cable and air piping
  • Weight: 3.9kg∗ Reduces the load on robots
    ∗ For ZGSNPK-400240BS4-RM1C8
  • CO2 emissions (Air consumption) (SMC comparison)
    Ejector with new design
    227 L/min (ANR) ← 270 L/min (ANR)
    Compared to ZL6H (Supply pressure: 0.6 MPa).

Electric Stopper Cylinder

Series LEB#

Electric Stopper Cylinder

  • Designed in response to customers' requests for a motorized conveyor line
  • With 2 control types available depending on the application
    Controller
    Controllerless
  • Ensured stopper cylinder mounting interchangeability with equivalent stopper performance
  • Easy replacement of shock absorbers Replaceable just by loosening the set screw.

ISO Standards (21287) Compact Cylinder

Series C55/CD55

ISO Standards (21287) Compact Cylinder

  • ISO Standards (21287)
  • 1.8 times the anti-lateral load capacity [New]
    The allowable lateral load has been improved by changing the material of the bushing (For ø20)
  • Increased the standard product's maximum stroke limit (to 300 mm) [New]
  • Standardization of the Double rod (C55W) type, Simple specials, and Made-to-order options [New]
    Change of rod end shape (-XA□)
    Heat-resistant cylinder (–10°C to 150°C) (-XB6)
    Low-speed cylinder (5 to 50 mm/s) (-XB13).

Compact Cylinder

Series CQ2/CDQ2

Compact Cylinder

  • Sizes Ø 4, Ø 6, and Ø 10 have been added. [New]
  • Ø 4 to Ø 200 lineup
  • Space-saving cylinder designed with a compact body
  • Small auto switches can be mounted on 4 surfaces. (1 surface for Ø 6 annd Ø 10, 2 surfaces for Ø 12 to Ø 25)
  • No projection of the auto switch
  • Weight: Reduced by 5 to 13% (Compared with the existing CQ2 series)
  • Newly added compact type foot brackets and double clevis pivot bracket
  • Part numbers with a rod end bracket and/or mounting bolt are available. (It is not necessary to order a bracket for the applicable cylinder separately.)
  • With auto switch (CDQ2 series: CDQ2, CDQ2W, CDQ2K, CDQ2KW, CDQP2, CDQ2#S, CDBQ2)
