Wireless System

Series EXW

Wireless System

  • Noise resistance
    Uses the 2.4 GHz ISM frequency band
    Frequency hopping: Every 2 ms (Fastest)
  • Communication cables not required
    Reduced wiring work, space, and cost
    Minimized disconnection risk
  • Provides communication stability in FA environments
  • Compact and lightweight (EXW1)
    Volume: Approx. 86 % reduction, Weight: Approx. 87 % reduction
  • Modular connection is possible (EX600-W).

Dust Resistant Cylinder

Series CQ2-Z

Dust Resistant Cylinder

  • Up to 6 times more durable in dusty environments
    Applicable powder particle size: 20 to 100 µm
    Suitable for environments with ceramic powder, toner powder, paper powder, and metallic powder
    * Excludes weld spatter
  • Can be selected according to the application
    A Lube-retainer (stable lubrication function) and a heavy-duty scraper can be mounted on the piston rod
    For the MGP series compact guide cylinder, they can also be mounted on the guide rod (one or both sides)
  • The rod cover assembly can be replaced according to the operating environment
    * Only for bore sizes Ø 20 to Ø 32 of the CQ2 series (Cannot be replaced for the MGP series).

High Speed Pilot Operated Solenoid Valve

Series DXT1215

High Speed Pilot Operated Solenoid Valve

  • High speed ON: 2.5 ms, OFF: 3 ms
  • Large flow rate: 330* l/min (ANR)
    * When the inlet side is 0.6 MPa, and the differential pressure is 0.1 MPa
  • Enclosure: IP67
  • Power saving: 1.5 W (With power-saving circuit)
  • Select from 3 or 5 port.*
    * 3-port type: Made to order (-X1)
  • Compact
    Overall length: 91.5 mm, Width: 16 mm, Height: 34 mm.

3-Screen Display High-Precision Digital Pressure Switch

Series ISE

3-Screen Display High-Precision Digital Pressure Switch

  • The ISE78G (16 MPa) and ISE79S (50 MPa) for general fluids has been added. [New]
  • It is possible to change the settings while checking the measured value
  • IO-Link
  • Angled display
    Good visibility from various mounting positions
  • Rotating display
    Display can rotate 336 degrees after installation
  • Applicable fluids: Air, Non-corrosive gas, Non-flammable gas (ISE70/71):
    Liquid or gas that will not corrode materials of parts in contact with fluid (ISE7□G/79S).

2-Layer Fluoropolymer Polyurethane Tubing

Series TUL

2-Layer Fluoropolymer Polyurethane Tubing

  • Flexible 2-layer tube with polyurethane outer layer
  • 2-layer construction (Outer layer: Polyurethane, Inner layer: Fluoropolymer)
  • Tubing I.D: Cross-section ratio increased by 44 % (Compared to TU0805).

Soft Start-up Valve

Series AV-A

Soft Start-up Valve

  • An air operated type (AVA series) has been added. [New]
  • A lockout type (AVL series) has been added. [New]
  • A start-up valve for low-speed air supply to gradually raise initial pressure in an air system and for quick exhaust by cutting off the air supply
  • Power consumption: 0.35 W
  • Improved flow rate characteristics: By up to 2.3 times (Q[l/min (ANR)]: 13447)
  • Energy saving: No air flow when the main valve is switched
  • Improved low-speed air supply adjustability
  • Smaller profile and less work required due to integrated silencer.

Compact Vacuum Unit Ejector System/Vacuum Pump System

Series ZQ#A

Compact Vacuum Unit Ejector System/Vacuum Pump System

  • Vacuum pressure switch with energy saving function
    Air consumption: 90 % reduction (Based on SMC's measurement conditions)
    Power consumption: 60 % reduction [0,4 W (Existing model) → 1 W]
    Vacuum release pressure: From 0 MPa [From 0 MPa (Existing model) → From 0.3 MPa]
    Copy function: Reduced setting labor, Minimized risk of setting mistakes
  • Compatible with ejector systems and vacuum pump systems.

Battery-less Absolute Encoder Type Electric Actuator High Performance Slide Table/High Precision Type

Series LESYH

Battery-less Absolute Encoder Type Electric Actuator High Performance Slide Table/High Precision Type

  • Reduces cycle time
  • Cycle time: Reduced by 39 % (0.61 s → 0.37 s) compared with the existing model
  • Acceleration/Deceleration: 10000 mm/s2
    (200 % increase compared with the existing model)
  • Max. speed: 800 mm/s (Improved by 200 % compared with the existing model)
  • Battery-less absolute encoder type
    Restart from the last stop position is possible after recovery of the power supply.

Stainless Steel Speed Controller with One-touch Fitting

Series ASG

Stainless Steel Speed Controller with One-touch Fitting

  • Improved environmental resistance with the all stainless steel exterior
    Possible for use in environments such as high temperature, water splashing, and where copper and zinc cannot be used
  • Max. operating temperature: 150 ℃
  • NSF H1 grease
  • Connection thread: Supports M5, R, and G
  • Material: Stainless steel 316 (Body A), FKM (Seal material)
    * Stainless steel 304 is used as the material for parts other than body A
  • Compact: Height reduced by 23 %, Lightweight: 42 g → 21 g.

Rotary Table/Rack & Pinion Type. Size: 10, 20, 30, 50

Series MSQ

Rotary Table/Rack & Pinion Type. Size: 10, 20, 30, 50

  • An external shock absorber option has been added. [New]
  • Compact and lightweight
    Height: Max. 28 % reduction* (54 mm → 39 mm)
    Weight: Max. 28 % reduction* (940 g → 680 g)
  • Enlarged centre hole diameter for piping (Ø 9 mm → Ø 12 mm)
    * Compared with the existing model (MSQ20)
  • The adjustable rotation time range is expanded. (0.2 to 2.0 s / 90°)
    Can be used at lower speeds compared with the existing product.
